Huawei’s AR3600 series enterprise router applies to medium and large-scale enterprise headquarters or branches.
Consult
|
Item |
Specification |
|
System parameters |
|
|
Processor |
6-core, 2.2 GHz |
|
Memory (default) |
8 GB |
|
Flash |
8 GB |
|
Micro SD card (default: sd1) |
Not supported |
|
Hard disk |
Supported |
|
Dimensions and weight |
|
|
Dimensions (W x D x H) |
· With no mounting bracket installed: 442.0 mm x 470.0 mm x 130.5 mm (17.4 in. x 18.5 in. x 5.14 in.), 3 U height · With mounting brackets installed: 482.6 mm x 470.0 mm x 130.5 mm (19.0 in. x 18.5 in. x 5.14 in.), 3 U height |
|
Weight |
11 kg (24.25 lb) |
|
Power specifications |
|
|
AC chassis model (700 W AC Power) |
Support double hot-swappable power modules |
|
Rated input voltage range (AC) |
100 V to 240 V, 50 Hz/60 Hz |
|
Maximum input voltage range (AC) |
90 V to 264 V, 47 Hz to 63 Hz |
|
Maximum input current |
10 A |
|
Maximum output power |
700 W |
|
RPS power supply |
Not supported |
|
PoE power supply |
Not supported |
|
AC PoE chassis model (850 W AC PoE Power) |
Support double hot-swappable power modules |
|
Rated input voltage range (AC) |
100 V to 240 V, 50 Hz/60 Hz |
|
Maximum input voltage range (AC) |
90 V to 264 V, 47 Hz to 63 Hz |
|
Maximum input current |
10 A |
|
Maximum output power |
850 W |
|
RPS power supply |
Not supported |
|
PoE power supply |
Supported |
|
Power consumption (empty chassis) |
|
|
Typical power consumption |
128 W |
|
Maximum power consumption |
184 W |
|
Heat dissipation |
|
|
Fan module |
Independent pluggable fan modules |
|
Airflow (facing the front panel) |
Left-to-right |
|
Interface density |
|
|
Management interfaces |
1 (RJ45) |
|
CON/AUX interface |
1 (RJ45) |
|
USB 2.0 interfaces |
2 |
|
Service interfaces (standard configuration) |
None |
|
Extended slots |
· 2xSIC · 7xWSIC |
|
Environment parameters |
|
|
Operating temperature |
0°C to 45°C (32°F to 113°F) NOTE: When the altitude is between 1800 m and 5000 m, the highest operating temperature reduces by 1°C every time the altitude increases by 220 m. |
|
Storage temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Operating relative humidity |
5% to 95%, noncondensing |
|
Operating altitude |
< 5000 m (16404.2 ft.) |
|
Part number |
02114484 |
|
Safety and Regulatory Standards |
|
|
EMC standards |
· CISPR32 Class A · EN 55032 Class A · CISPR24 · EN 55024 · ETSI EN 300 386 · AS/NZS CISPR32 Class A · FCC Part 15 Subpart B Class A · ICES 003 Class A · IEC 61000-3-2 · EN 61000-3-2 · IEC 61000-3-3 · EN 61000-3-3 · GB 9254 · VCCI-CISPR32 Class A |
Application
The AR3600 series enterprise router provides strong openness and scalability, various applications, and centralized management. It can be deployed in schools. With the flexible and open X86 platform, the AR3600 can quickly integrate third-party application software, such as the teaching software and courseware player. It provides more and more application services for school information, realizing information teaching management. The AR3600 connects the school network to the education network and Internet to implement education resource sharing and fast query
